As for crude oils of high viscosity, which are condensed into solid blocks at room temperature, floating or shifting in waters, and are difficult to be retrieved by a mechanical recovery device. A better recovery can be made with the oil trawl. The oil trawl is mainly composed of a frame, buoy, main net, dragnet and nylon fabric bag. The dragnet is detachable from the main net. When the net is full, it can be replaced with a new one.
|
Model
Parameter |
SW-2 |
SW-3 |
SW-4 |
SW-5 |
SW-10 |
|
Frame Size(mm) |
2150×650×1080 |
2150×650×1080 |
2150×650×1080 |
2150×650×1080 |
2150×650×1080 |
|
Net Bag Volume(m3) |
2 |
3 |
4 |
5 |
10 |
|
Mesh Size |
5×5 or 10×10 |
||||
|
Towing Speed (Kn) |
0.5～1 |
0.5～1 |
0.5～1 |
0.5～1 |
0.5～1 |
|
Package Box Size (mm) |
2280×1230×870 |
2280×1230×870 |
2280×1230×870 |
2280×1230×870 |
2280×1230×870 |
|
Boom Arm
|
10.5m (It can be configured according to the user’s needs. ) |
||||
|
Containment Boom for Trailing |
Type 1000*10m, 2 pieces (It can be configured according to the user’s needs.) |
||||
