The OIL SPILL DISPERSANT SPRAYING DEVICE is mainly used to spray oil spill dispersants, clean up oil spill pollution on waters, shoal, rock, building and other sites. It can also be used to clean containment booms, skimmers and other devices.

FEATURES OF OIL SPILL DISPERSANT SPRAYING DEVICE:

The spraying device is mainly divided into hand-held oil spill dispersant spraying device and marine fixed oil spilling dispersant spraying device.

The hand-held dispersant spraying device for oil spill is installed on the trolley, which is flexible and easy to operate. It is suitable for removing oil spill in small area on water surface, wharf, beach, reef and indoor occasions.

The marine fixed dispersant spraying device for oil spill is a large spraying device mounted on both sides of the ship. It is composed of hydraulic pump station, spraying arm, handheld spray gun and etc. It can be carried along with the ship to clean up large areas of oil spill on the water surface.

More +

Technical Specification

Model

Parameter

PS40

PSB80

PSB120

PSB160

Max. Flow RateL/min

40

80

120

160

Working PressureMPa

1~4

0.3~0.5

0.3~0.5

0.3~0.5

Length of Suction Armm

/

6

0.3~0.5

6

Quantity of Spray Heads (Piece)

/

10

10

10

Max. Spraying Distance

of Spray Gunm

12

12

12

10

Power Station Power (Diesel Engine or Explosion-proof Motor)(KW)

4.0/2.2

6.3/4

6.3/5.5

6.3/5.5

Spray Gun

1

2

2

2


Note: The technical data are subject to change without notice due to modifications to the product and shall be confirmed by the manufacturer and customer.
