The EMERGENCY UNLOADING DEVICE is mainly used for the timely transfer of oil product inside the ship in case of maritime accident. It can reduce oil overflow and prevent oil pollution rapidly and effectively, protecting the ecological environment. The equipment is widely used in marine harbors, port terminals, shipyards and other occasions where ship oil spills and needs to be unloaded.

It consists of the storage and transportation platform, unloading pump, explosion-proof motor type (explosion-proof diesel model), hydraulic power station, pipe reel, oil hose, hydraulic hose, spare parts and maintenance toolbox.

Technical Specification

Item

Parameter

Model

XZB-20F

XZB-50F

XZB-80F

XZB-100F

XZB-200F

XZB-300F

Max. Oil Transportation RateT/h

20

50

80

100

200

300

PowerKW

(Explosion-proof Motor)

18.5

30

30.0

45.0

55.0

75.0

PowerKW

(Explosion-proof Diesel)

22

22

22

40

40

40

Working Pressure of the Hydraulic MotorMPa

4~10

5~12

6~14

6~14

8~14

10~16

Allowable Working Temperature of the Hydraulic Oil,℃

60

Lift of Pumpm

≥30

Tubing Size

3”

4”

5”

6”

6”

8”

Pump Head Weightkg

120

140

150

250

250

350

Hydraulic Power Station Weightkg

1000

1000

1000

1150

1150

1150


Note: The technical data are subject to change without notice due to modifications to the product and shall be confirmed by the manufacturer and customer.
