对于高粘度的原油,常温下凝结成块状固体,漂浮在水面或悬浮在水中,机械收油设备难以回收,使用油拖网可得到较好的回收效果。
油拖网主要由框架、浮体、主体网、拖网、尼龙布袋组成。
拖网与主体网可分离,收满时可更换拖网。
型号Model
参数Parameter |
SW-2 |
SW-3 |
SW-4 |
SW-5 |
SW-10 |
框架尺寸(mm) Frame Size |
2150×650×1080 |
2150×650×1080 |
2150×650×1080 |
2150×650×1080 |
2150×650×1080 |
袋网容量(m3) Net Bag Volume |
2 |
3 |
4 |
5 |
10 |
网眼尺寸 Mesh Size |
5×5或10×10 (5×5 or10×10) |
||||
拖拽速度(Kn) Towing Speed |
0.5~1 |
0.5~1 |
0.5~1 |
0.5~1 |
0.5~1 |
包装箱尺寸(mm) Package Box Size |
2280×1230×870 |
2280×1230×870 |
2280×1230×870 |
2280×1230×870 |
2280×1230×870 |
悬臂 Boom Arm |
10.5m(可根据用户需求配置) It can be configured according to the user’s needs. |
||||
拖带用围油栏 Containment Boom for Trailing |
1000型×10m,2条(可根据用户需求配置) Type 1000*10m, 2 pieces (It can be configured according to the user’s needs.) |
