INFLATABLE RUBBER OIL BOOM is a major emergency equipment to prevent oil spill from spreading and transferring in oil spill accident. The main supporting equipment includes a power station, a filling and suction machine, a tractor, a reel frame and a container. It is widely used in open sea, harbor, wharf, river, offshore oil platform and ship rescue and other oil spill waters.
The framework of the inflatable oil boom is made of double-layer high-strength nylon canvas, coated with oil-resistant and aging resistant high-quality synthetic rubber.
The unique air valve design allows for easy and speedy inflation and perfect air-tightness.
Elastic supporting bars are set between the air chambers to make the oil boom quite stiff to effectively prevent wave from overtopping.
The tight tensile ballast chains can effectively prevent the damage of oil boom.
Luminous mark or rubber color on the outside of oil boom is provided for easy identification.
Rubber oil boom with flame retardant characteristics is provided for high fire protection level.
It can be supplied with accessories such as boom tractor, towing rope, anchor block and etc., according to customers’ requirements.
|
Model Parameter |
WQJ800 |
WQJ1000 |
WQJ1200 |
WQJ1500 |
WQJ1800 |
WQJ2000 |
WQJ2500 |
|
Overall Height (mm) |
800 |
1000 |
1200 |
1500 |
1800 |
2000 |
2500 |
|
Freeboard (mm) |
280 |
360 |
400 |
500 |
560 |
600 |
810 |
|
Draft (mm) |
370 |
430 |
590 |
780 |
950 |
1100 |
1400 |
|
Length per Section (m) |
100/200 |
||||||
|
Max. Working Tensile Strength(KN) |
110 |
140 |
170 |
190 |
230 |
260 |
280 |
|
Max. Resistance to Wave Height (m) |
2 |
2 |
2.5 |
3 |
3 |
4 |
4 |
|
Max. Resistance to Wind Speed (m/s) |
15 |
15 |
20 |
20 |
20 |
25 |
25 |
|
Max. Resistance to Current Speed (Kn) |
2～3 |
3 |
3～4 |
3～4 |
3～4 |
3～4 |
3～4 |
